Double Temperatruer Showcase

Place of Origin: Guangdong, China (Mainland) Min.Order Quantity:1 Forty-Foot Container Supply Ability:12000 Set/Sets per Month Payment Terms:L/C,T/T Brand Name: DUKERS/OEM Model Number: LDG-228

Send Inquiry Chat Now

Description

Double Temperatruer Showcase

Quick Details

Model Number: LDG-228 Type: Display Cooler

Style: Double-temperature Certification: CE ROHS GS

Capacity: 210L Temperature: ≤-15 / 0~10 (℃)

Climate Type: ST Refrigerant: R134a

Packaging & Delivery

Delivery Detail:

35days

Specifications

1)Direct cooling system
2)Mechanical control
3)Fashion appearance
4)Double temperature showcase
5)Low energy consumption

Product Description

MODEL	LDG-228	LDG-298	LDG-348
Net (Liters)	210	280	320
Net (CB FEET)	7.4	9.9	11.3
Volume of top freezer(Liters)	40	65	90
Cooling system	Direct cooling	Direct cooling	Direct cooling
Auto-Defrost	No	No	No
Control system	Mechanical	Mechanical	Mechanical
External Dimension WxDxH (mm)	530x603x1565	620x603x1645	620x595x1845
Packing Dimensions WxDxH(mm)	580x655x1615	685x665x1696	685x625x1904
Weight net /Weight gross (kg)	Pending	Pending	Pending
40' HQ Container	101	75	73
Glass Door type	Hinge door	Hinge door	Hinge door
Door frame, door handle material	PVC	PVC	PVC
Glass type, (tempered)*	Normal	Normal	Normal
Door Auto Closing	For option	For option	For option
LOCK	YES	YES	YES
Type	R141b	R141b	R141b
Dimensions (mm)	50(average)	50(average)	50(average)
Adjustable shelves (pcs)	3	3	3
Adjustable Rear Wheels (pcs)	2	2	2
Front Feet (Wheels for Option)	2 Feet	2 Feet	2 Feet
Internal light vert./hor.*	Horizontal*1	Horizontal*1	Horizontal*1
Voltage/frequency	220~240V/50HZ	220~240V/50HZ	220~240V/50HZ
Power consumption (w)	Pending
Amp. Consumption (A)
Energy consumption (kWh/24h)
Upper temperature	<-15 0C	<-15 0C	<-15 0C
Lower temperature	0~10 0C	0~10 0C	0~10 0C
Temperature digital screen	No	No	No
Climate Class As per EN441-4	Class 3	Class 3	Class 3
Max. Ambient Temp. 0C	38 0C	38 0C	38 0C
Refrigerant (CFC-free)	R134a	R135a	R136a
Outer Cabinet	Pre-painted steel	Pre-painted steel	Pre-painted steel
Inside Cabinet	Pre-painted aluminium	Pre-painted aluminium	Pre-painted aluminium
Condenser	backside Mash Wire	backside Mash Wire	backside Mash Wire
Evaporator	In Insulation	In Insulation	In Insulation
Evaporator fan	14W Square fan	14W Square fan	14W Square fan
Certification	CE,ROHS	CE,ROHS	CE,ROHS
